Fabricated Trailing Arms
Derived from our trailing arm kits, we are offering our fabricated trailing arms for purchase by themselves. Constructed from 2” .25” thick tubing and a mix of 3/16” & 1/4” mild steel plate. Trailing arms are mig welded. These arms use a 1.25” heim joint at the chassis side and a 1” uniball at the axle size. Shock mount eyelet is 7/8” below the centerline of the trailing arm, eliminating the need for any type of bushing or wobble stopper. Available in custom sizes, call for more info.
Dimensions: 42.5” eye to eye
Distance from chassis side pivot to shock eyelet: 34.5”
Distance from shock eyelet to axle side pivot: 8”
Shock mounting width: 1.5”
Included with purchase:
-2 Fabricated trailing arms
-2 1.25” heims
-2 1” uniballs
-8 Misalignment spacers for 3/4” bolts
-4 3/4” grade 8 bolts
-2 1/2” shock bolts
DISCLAIMER
All products developed and created by MarTec LLC are intended for off-road use only and hold no warranty.
